Dometic CFX5 55IM Electric Cooler with Ice Maker
The CFX5 55IM is the CFX5 model for builders who want a serious powered cooler but also like the idea of making ice at camp. It keeps the main storage area useful for food and drinks while the integrated ice maker handles the small luxury that usually requires a separate bag of ice.
For a Jeep, Bronco, truck, van, or trailer setup, the 55IM is a practical middle size. It has 55 L of volume, runs from vehicle or camp power, and uses VIP insulation plus a compressor system designed for efficient cooling without the mess and space loss of traditional ice.
Quick Highlights
- 55 L electric cooler with integrated ice maker
- Single-zone fridge/freezer operation with dedicated ice-making function
- Holds up to 84 standard 12 oz cans
- 100-240 V AC and 12/24 V DC power compatibility
- VIP insulation, VMSO 3.5 compressor, and electronic thermostat
- Bluetooth/app control, high-resolution display, and USB port
- M6 threaded inserts, drain plug, removable baskets, and bottle opener
Best Fit
- Weekend and multi-day builds where 55 L is enough food volume without consuming the entire rear cargo area.
- Camp kitchen setups where fresh ice is useful but a separate ice chest is not.
- Slide-mounted installs where you want powered cooling, good access, and less wasted cargo space.
Power and Control
- Rated AC input power is 55 W, with 100-240 V AC support.
- Rated DC draw is 8.5 A at 12 V or 4.0 A at 24 V.
- Energy consumption is 1.55 Ah/h at 12 V DC with the internal compartment at 4 °C and the ice maker in maintenance mode at 32 °C ambient.
Specs That Matter in a Vehicle Build
- Total volume: 55 L
- Can capacity: Up to 84 12 oz cans
- Zones: Single zone with ice maker
- Exterior size: 28.4 in D x 17.9 in W x 18.9 in H
- Net weight: 44.4 lb
- Input power: 100-240 V AC or 12/24 V DC
- Rated AC input: 55 W
- Rated DC current: 8.5 A at 12 V / 4.0 A at 24 V
- Model: CFX555IM
Why It Works for Overlanding
The CFX5 line is built around ice-free cooling, efficient insulation, vehicle-friendly power options, and hardware that makes sense in a moving cargo area. That combination is why these coolers fit naturally into overland builds where food storage, power draw, and access all have to be planned together.
Whether you call it a powered cooler, portable fridge/freezer, 12V fridge, or electric cooler, the job is the same: keep food cold without ice while fitting the vehicle, power system, and cargo layout around it.
For AAL customers, the decision usually comes down to size and zone layout. Choose the capacity that fits your trip length, passenger count, and cargo system, then leave enough room for the gear that still needs to ride beside it.
Dometic CFX5 FAQ
Is a Dometic CFX5 a cooler or a 12V fridge/freezer?
The CFX5 is an electric cooler. In vehicle-based travel, shoppers also call this type of compressor-cooled box a powered cooler, portable fridge/freezer, 12V fridge, or 12V refrigerator/freezer because it cools from power instead of ice.
Does the CFX5 55IM make ice?
Yes. The 55IM includes an integrated ice maker, which is the main reason to choose it over the non-ice-maker CFX5 45.
Is the 55IM dual zone?
No. It is a single-zone cooler with an ice-making feature. If you need separate fridge and freezer compartments, look at the CFX5 75DZ or 95DZ.
What comes in the box?
It ships with the cooler, manual, warranty card, 12/24 V connection cable, 100-240 V connection cable, removable wire baskets, and bottle opener.
