Flat Form Factor

The 19.49 x 24.41 x 1.85 in. housing gives builders more placement options than a traditional upright battery, especially in low-clearance cargo and platform systems.

150Ah Capacity

With 12.8V nominal voltage and 1,920Wh of stored energy, this battery is sized for larger auxiliary power builds running fridges, lighting, camp electronics, radios, compressors, and other sustained loads.

LiFePO4 Chemistry

LiFePO4 construction provides long cycle life, superior stability, lower weight than comparable lead acid batteries, and strong discharge performance.

Expandable System

The modular design supports up to four batteries in parallel and/or four batteries in series for builds that need more capacity or different system voltages.

Applications

Built for mobile and remote power systems.

This higher-capacity flat battery is a strong match for overlanding, off-grid power, marine, recreation vehicle, electric vehicle, energy storage, and van life applications. Its flat shape is especially helpful when the battery needs to disappear into a shelf cavity, platform, drawer stack, or other tight packaging area.

For American Adventure Lab PowerPack Rack builds, the KC flat battery format gives you a cleaner way to integrate auxiliary power without handing over your whole cargo floor to a battery box.

Charging and Discharge

Designed for high-output auxiliary power systems.

Charge voltage is listed at 14.20VDC to 14.60VDC, with float voltage listed at 12.80VDC to 13.50VDC. Discharge cut-off voltage is 10V, and charger cut-off voltage is 15.0V plus or minus 0.1V.

Temperature and Protection

Ready for real-world environments.

Operating discharge temperature is listed from -4F to 140F (-20C to 60C). Charge temperature is listed from 32F to 113F (0C to 45C). The battery carries an IP65 water and dust resistance rating.
